IntelliGEN™ Series
Briggs & Stratton 30kW model 76000 and 45kW model 76001
Liquid Cooled Home Generator Systems
Natural Gas & Propane Emergency Generators

30kW and 45kW Liquid Cooled

Computer Controlled for Maximum Efficiency
30kW Generator $$ Pricing

Briggs & Stratton is proud to offer the new IntelliGEN™ Series 30kW and 45kW Liquid Cooled Home Generator Systems. Boasting world class GM Vortec engines and 4 pole 1800 rpm alternators, these new systems offer true whole house comfort and control in an extremely compact, quiet & affordable package. The standard 30kW and 45kW packages supply enough quiet automatic backup power to manage the demands of most larger homes. The optional high efficiency computercontrolled power management system provides optimal performance, making them the most eco-friendly standby generators in their class.

Computer Friendly - ULlisted


The new IntelliGEN™ Series 30kW and 45kW Liquid Cooled Home Generator Systems
- Premium Features for Premium Comfort

  • Fully Automatic – Advanced electronics will detect a utility power outage and automatically start the generator whether you are home or away.
  • GM Vortec Engine – Tested and approved on trucks and SUVs, world class 4 and 8 cylinder GM Vortec engines provide sophisticated yet extremely durable industrial grade power - perfect for the high power demands of most larger homes.
  • Computer Friendly Power – A long life, commercial grade 4 pole 1800 RPM alternator provides robust, quiet, ultra smooth electricity, perfect for larger ‘smart’ homes.
  • Sound Shield™ Technology – Engineered air flow, an automotivestyle exhaust system, acoustic foam dampeners, and low 1800 RPM engine ensure quiet operation. (65 dB under normal load)
  • Durable All-Climate Enclosure – The durable storm grey steel enclosure is powder coat painted for excellent adhesion and improved resistance to chipping, abrasion & corrosion - perfect for years of all season outdoor protection.
  • Turn Key Extras – Each IntelliGEN™ Series system includes a battery charger and hour meter. The engine also comes pre-filled with oil and is pre-run at the factory, saving you time & money.
  • Premium Warranty – 4 year limited - your guarantee of quality and performance.
  • Legendary Service & Support – From professional sizing and delivery to installation & service, trust the proven experts at Briggs & Stratton for complete peace of mind.




STATSTATION™ WIRELESS Power MONITORING UPGRADE – Model # 40238

STATSTATION™ WIRELESS Power MONITORING UPGRADE



You’ll never need to leave your house to communicate with your IntelliGEN™ generator.
The StatStation™ is a wireless, handheld LCD monitor that gives you detailed, easy-to-read reports on your IntelliGEN’s system status, diagnostic test results, real-time power performance and more – all from the safety of your home.










  30kW 45kW
Model Number 76000 76001
IntelliGEN™ Power Management Optional Upgrade Optional Upgrade
Watts LP/NG 30,000W (LP)/27,000W (NG) 45,000W (LP)/42,000W (NG)
Starting Watts LP/NG 37,500W (LP)/33,000W (NG) 56,000W (LP)/53,000W (NG)
Engine GM Vortec 3.0L inline 4 cylinder GM Vortec 5.0L V8
Operating RPM 1800
Electronic Governing Yes
System Operation Fully Automatic
Voltage 120/240V AC, Single Phase, Electronic Regulation
Amps LP/NG 125/112.5 187.5/187.5
Alternator 4-pole, brushless
Full Pressure Lubrication Yes
Fuel Type Propane (LP Vapor) & Natural Gas
Fuel Consumption (@ 1/2 Load)*
FT3/HR (M3/HR)
92 (2.6) LP
259 (7.3) NG
178 (5.0) LP
483 (13.7) NG
Overcrank Protection Yes
Sound Rating (normal operation) 65 dB
Remote StatStation™
Diagnostic Alerts
Low Oil Shutdown, Fail to Start, Low Frequency, Engine Overspeed, Low Voltage, Low Battery Voltage, Oil Temp High and Transfer Switch Fault
Turn-Key Extras Included Battery Charger, Full Diagnostics, Engine Block Heater
Dimensions (L×W×H) 84.5" x 39.5" x 41.5" 98.5" x 39.5" x 44"
Weight (generator only) 1800 lbs. 2100 lbs.
Warranty 4 Year or 3000 Hour Limited

*Fuel consumption rates are estimated based on normal operating conditions at ½ load. Generator operation
may be greatly affected by elevation and the cycling operation of multiple electrical appliances – fuel flow rates
may vary depending on these factors






Transfer Switch Specifications (Sold Separately)
Model Number 71036
Common Features 120/240 Voltage, 2 Poles, 60 Frequency, AC Power Control Module, (ACCM-III), Nema 3R Indoor/Outdoor Enclosure,
UL 1008 Listed
Power Management Method Equipped with Patented AC Power Control Module™
Circuits Whole House
Amps 200A
Service Entrance Disconnect Yes*
Dimensions (L×W×H) 33" x 10.25" x 19"
Weight 64 lbs.

*Review local codes to determine if a transfer switch with separate service entrance disconnect is required.


AVAILABLE ACCESSORIES

GenAlert™ Phone Dialer - Monitors your Home Generator System’s performance, automatically calling you via telephone if a problem has occurred. Model: 40205

GenAlert™ Plus Phone Dialer - Adds to GenAlert the ability to check current temperature and power status in your home. Calls up to 3 separate numbers. Model: 40206

Battery Warmer - Ensures reliable starting in cold weather climates. Model: 1915

Trust The Power Experts
From product selection and installation to legendary service & support, you can count on Briggs & Stratton’s extensive network of power experts to safeguard your home and family when the power goes out.


Inteligen High Efficiency Upgrade - Model 71035 Featuring patented computer-controlled technology, the IntelliGEN High Efficiency upgrade is designed to expand your generator's range and performance by automatically prioritizing and managing multiple high demand appliances. The end result: Advanced computer controls provide seamless, highly efficient whole house power with up to 50% less fuel consumption, 50% less sound, lower emissions and exclusive overload protection.
